High Frequency PCB
High Frequency PCB is a type of PCB used for signal transmission in the
variety of applications including mobile, microwave, radio frequency
and high speed design applications.
High Frequency boards come with high frequency laminates are difficult
to fabricate because they need to maintain thermal heat transfer of the
application, in view of the sensitivity of the signal.
Special materials are used to attain the high frequency given by the High Frequency PCB.
Characteristics of the high frequency board can effect the overall
performance of the signal, similarly any change in the Er value of the
materials used can widely impact the impedance of the board.
Most of the professionals prefer rogers dielectric material because it
turns out to be less expensive, have low DK and DF value, reduced signal
loss and appears to be suitable for fabrication and prototyping
applications.
Teflon is another common material used in the manufacturing process of
the high frequency PCB, which comes with frequency of 5GHz.In terms of
DK, DF and water absorption factor, Teflon is the best, but more
expensive than FR4.
If your projects requires frequency more than 10GHz with higher quality and stable signal, then Teflon is the best choice.
High frequency signals are vulnerable to noise and come with much
tighter impedance tolerance as compared to conventional circuit boards.
